Household DC Inverter Air to Water Source Heat Pump with Tube-in-Shell Heat Exchanger
Product Details:
| Place of Origin: | Shandong, China |
| Brand Name: | BAIDIAN |
| Model Number: | 8P |
Payment & Shipping Terms:
| Price: | $880.00/pieces 1-49 pieces |
|---|---|
| Packaging Details: | Paper packaging |
| Supply Ability: | 500 Piece/Pieces per Day |
|
Detail Information |
|||
| After-sales Service Provided: | Free Spare Parts | Warranty: | 1 Year |
|---|---|---|---|
| Application: | Outdoor, Hotel, Commercial, Household | Power Source: | Electric |
| App-Controlled: | NO | Private Mold: | NO |
| Type: | Air Source Heat Pump, Air Source Inverter Heat Pump | Installation: | Wall Mounted |
| Storage / Tankless: | Storage | Housing Material: | Stainless Steel |
| Use: | Bathroom, Jacuuzi | Function: | Hot Water *Space Heating*Space Cooling |
| Refrigerant: | R410A | Heat Exchanger: | Tube-in-shell Heat Exchanger |
| Heating Capacity: | 3 Kw | Compressor: | DC Inverter Compressor |
| Name: | Swimming Pool Air Source Heat Pump | Power Supply: | 220~240V/1Ph/50~60Hz |
| Heat Source: | 75% Air Source+25% Electricity | Port: | QINGDAO TIANJIN |
Product Description
Product Description
Specification
Model No. | YT-120TA1 | YT-180TA1 | ||
Heating Capacity at Air 20℃/15℃, Water Temperature from 15℃ to 55℃ | ||||
Heating Capacity(kW) | 2 | 2 | ||
Power Input(kW) | 0.51 | 0.51 | ||
COP | 3.92 | 3.92 | ||
Max Power Input(kW) | 2.4 | 2.4 | ||
Rated Current(A) | 2.6 | 2.6 | ||
Max Current(A) | 12.2 | 12.2 | ||
Power Supply | 220V/1/50Hz | 220V/1/50Hz | ||
Backup Electric Heater(W) | 1500 | 1500 | ||
Refrigerant | R410A | R410A | ||
Net Dimension(mm) | 500×500×1628 | 500×500×1848 | ||
Package Dimension(mm) | 680×680×1805 | 680×680×2025 | ||
Net Weight(Kg) | 75 | 93 | ||
Noise(dB) | 48 | 48 | ||
Water tank volume(L) | 120 | 180 | ||
Working temperature range(℃) | -7~43 | -7~43 | ||
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine
PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
FAQ
Q1: How many years have your company been in heat pump industry?
A: We has full experience in the field of heat pumps for more than 13 years. JNOD has kept growing rapidly during these years
since it was established. In 2020, more than 60% of our heat pump products were exported to Europe, North America , Middle East,
Australia, and other developed regions.
Q2: Do you accept OEM & ODM?
A: Yes. We can produce standard products under clients' brand, modify the products to satisfy client's personalized requirements
and work together with clients to design and produce a totally new products.
Q3: What support do you offer to clients?
A: We can: provide product certification requirements for local markets; provide catalogs, technical manuals; co-exhibit with the
clients in leading industry exhibitions; do promotion on the local market’s media by our news release resources.
Q4: Will you provide technical promotion support?
A:Of course,we can provide corresponding pictures and videos to you.
A: We has full experience in the field of heat pumps for more than 13 years. JNOD has kept growing rapidly during these years
since it was established. In 2020, more than 60% of our heat pump products were exported to Europe, North America , Middle East,
Australia, and other developed regions.
Q2: Do you accept OEM & ODM?
A: Yes. We can produce standard products under clients' brand, modify the products to satisfy client's personalized requirements
and work together with clients to design and produce a totally new products.
Q3: What support do you offer to clients?
A: We can: provide product certification requirements for local markets; provide catalogs, technical manuals; co-exhibit with the
clients in leading industry exhibitions; do promotion on the local market’s media by our news release resources.
Q4: Will you provide technical promotion support?
A:Of course,we can provide corresponding pictures and videos to you.
Want to Know more details about this product
